SWC-WH无伸缩焊接型十字万向联轴器

型号回转
直径
D/
mm
公称
转矩
Tn/
KN ·m
疲劳
转矩
Tf/
KN ·m
轴承
寿命
系数
KL
轴线
折角
β/
(°)
尺寸/mm转动惯量/
(kg ·㎡)
质量/
kg
 LminD1
(js11)
D2
(H7)
 D3Lmn×φdktb
(h9)
gLmin/
mm
增长
100mm
Lmin/
mm
增长
100mm
SWC100WH1002.51.255.795×10-4≤25243845760556×φ972.50.0040.00024.50.35
SWC120WH12052.54.641×10-3≤253071027570658×φ1182.5一  0.010.00047.70.55
SWC150WH1501050.51×10-1≤253501309089808×φ131030.0370.0016180.85
SWC180WH18022.411.20.245≤154801551051141108×φ171752470.150.007482.8
SWC200WH20036181.115≤155001701201331158×φ171752880.2460.013723.7
SWC225WH22556287.812≤155201961351521208×φ172053290.3650.023784.9
SWC250WH25080402.82×101≤156202181501681408×φ192564012.50.8470.0281245.3
SWC285WH285120588.28×101≤157202451701941608×φ2127740151.7560.0511856.3
SWC315WH315160802.79×102≤1580528018521918010×φ2332840152.8930.082628
SWC350WH3502251107.44×102≤1587531021024519410×φ2335850164.8140.14634911.5
SWC390WH3903201601.86×103≤1595534523526721510×φ2540870188.4060.22250615
SWC440WH4405002508.25×103≤15115539025532526016×φ284210802015.790.47479021.7
SWC490WH4907003502.154×104≤15120543527535127016×φ3147129022.527.780.690110427.3
SWC550WH55010005006.335×104≤15135549232042630516×φ31501210022.548.321.357152634

《SWC-WH无伸缩焊接型十字万向联轴器》由Rokee发布于2022年2月14日
